HiStone Terminal Quad Core J6412 Fanless HK568 with Windows 10 IoT
Item #: 721068 NOCR
The Histone HK568 15.6" widescreen touch terminal presents a contemporary look with ultimate flexibility and high performance. Extra workspace and adjustable design make the HK568 an excellent option for any application. Rotate the display vertically and add the SNBC BTP-S80 Cube printer to create aesthetically pleasing kiosk stations with a small form factor.
• Intel Elkhart Lake Quad Core J6412 Fanless Processor
• Solid State Drive
• Projected Capacitive Touch (PCT) For Optimum Performance and Reliability
• 15.6" Screen / 16:9 Aspect Ratio
• Vivid LED Backlight
• Reduce Workstation Footprint and Cable Clutter With the Optional CUBE-X Housing For an Integrated 2D Scanner and Thermal Printer Solution
• Compatible with Popular Application Software
SPECIFICATIONS
| Processor: | Intel Celeron Quad Core J6412 |
| Cores / Threads | Quad Core / 4 Threads |
| Cache Memory: | 2MB |
| Display LCD: | True Flat 15" LCD with LED Backlighting |
| Resolution: | 1920 X 1080 |
| Brightness: | Adjustable Up to 250 cd/m |
| Integrated Speakers: | Integrated 2 Watt Speakers |
| Chipset (PCH): | CPU integrated |
| Touch Panel: | Projected Capacitive Touch |
| Hard Drive: | 128GB 2.5" Solid State Drive |
| RAM Memory (1 Slot): | 4GB SODIMM DDR4 (3200MHz) Expandable To 16GB |
| Video Memory: | Shared System Memory Up To 256MB |
| Tilt Adjustment | 0° ~ 45° (Vertical) |
| Serial Ports |
External: COM1 / COM2 / COM3 = RJ48 |
| USB Ports | One USB 24V Powered (120W Power Supply Required) / Four V2.0 / Two V3.0 |
| Cash Drawer Port: | RJ12 (24V) – Dual Cash Drawer – Supports Open/Close |
| HDMI Port | One |
| LAN Port: | RJ45 100M/1000M Gigabit LAN |
| VGA Port | Not Applicable |
| Audio Port: | One Line-Out |
| Mic Port: | Not Applicable |
| Power Supply: | 60W, 24V/2.5A External Power Adaptor 100-240V 50-60Hz |
| Current / Power Usage: | 0.20A / 24W |
| Environment: | Operating: 32° F to 113° F / 10% to 90% RH Non-Condensing Storage: 14° F to 158° F / 10% to 90% RH Non-Condensing |
| Compatible O/S: | Windows 10 / Windows 11 / Professional |
| Dimen. / Weight - Base: |
Overall: 15-3/4”W x 8”D x 15”H 14.33 lbs. |
| Safety and EMI: | FCC / CE / RoHS |
